Company Profile
Shenzhen MinewSemi Co., Ltd. is an innovative IoT module expert integrating product research and development, technical application and service support. We offer IoT connectivity module products for companies that rely on mission-critical connectivity and enterprise-grade performance.
Main Business
With over 10 years of IoT module innovation experience, we are capable of independently developing and producing high-performance IoT modules, including BLE, GNSS, WI-FI, LoRa, UWB, mmWave Radar, and other comprehensive IoT module products. Besides reliable, convenient, safe and intelligent IoT solutions for almost all vertical industries, we are also geared to customize the best and optimal IoT modules and solutions catering to your special requirements. Also, our IoT modules can be used individually or bundled into a comprehensive solution to reduce time-to-market and cost.
Main Products
CISC NFC Xplorer Inline
Description：
Product Description:
The ME54BS62 is an ultra-compact Bluetooth 6.0 module designed for space-constrained devices. Built on the Nordic nRF54L15 SoC, it integrates a PCB onboard antenna, delivering a highly integrated, ready-to-use wireless solution. With a footprint of just 6×9mm, it significantly reduces RF design complexity while maintaining stable and reliable connectivity. Leveraging Bluetooth 6.0, it enables enhanced connection performance and high-precision ranging capabilities, making it ideal for next-generation smart devices.
Key Features:
Ultra-compact size: 6×9mm for space-limited designs
nRF54L15 SoC, Arm® Cortex®-M33 @ 128 MHz
Integrated PCB antenna for simplified development
Bluetooth 6.0 with Channel Sounding for precise ranging
30 GPIOs, TWI / SPI / I2S / UART / PWM
Low power consumption for extended battery life
Ideal for Matter, SmartThings Find, Aliro, Google Find Hub…
Applications:
AR/VR devices, Wearables, Game controllers, Smart home devices, Portable medical equipment
CISC NFC Xplorer Inline
Description：
Product Description:
The ME54BS12 is a high-performance Bluetooth 6.0 multi-protocol module built on the nRF54L15 platform, offering enhanced processing capability and system scalability. It supports multiple IoT protocols including Bluetooth, Zigbee, Thread, and Matter, enabling seamless connectivity in complex IoT ecosystems. With ample memory resources and rich GPIO interfaces, it provides flexibility for advanced application development while maintaining efficient power consumption.
Key Features:
Equipped with Arm® Cortex®-M33 @ 128 MHz
Supports nRF54L15/L10/L05 chips (optional)
128 MHz Arm Cortex-M33
Compact size: 15.8×12×2mm
Strong RF performance: -40~+7 dBm TX, -96 dBm RX
-40°C to +105°C operating range
Up to 29 configurable GPIOs
Supports Bluetooth LE 6.0 Channel Sounding
Bluetooth Mesh, Zigbee, Thread, Matter, Amazon Sidewalk, and more
Applications:
Smart home (gateways, smart locks, lighting), Industrial IoT, Wearables, PC peripherals, Environmental monitoring
CISC NFC Xplorer Inline
Description：
Product Description:
The ME25LS04 is a third-generation multi-band LoRa module based on the Semtech LR1121 chipset, supporting Sub-GHz, 2.4GHz, and S-Band satellite communication. It enables seamless integration of terrestrial and satellite networks, delivering ultra-long-range connectivity even in remote or infrastructure-limited environments. With support for both LoRa and LR-FHSS modulation, it ensures reliable data transmission in challenging conditions and supports global deployments.
Key Features:
Equipped with the Semtech LR1121 LoRa transceiver
Supports global ISM Sub-GHz and 2.4GHz bands, as well as S-band satellite connectivity
Low-power design with SPI interface, compact and easy to integrate
+22dBm transmit power, enabling up to 4KM LoRa communication range
High sensitivity of -126dBm @SF7, ensuring stable connectivity under weak signal conditions
Supports LR-FHSS for strong anti-interference and reliable long-range transmission
Built-in industrial-grade TXCO crystal oscillator for precise timing and stable operation
Supports LoRa®, LoRaWAN standard communication, and satellite communication
Applications:
Asset tracking, Smart agriculture, Emergency communication, Smart city infrastructure, Marine and mining environments
CISC NFC Xplorer Inline
Description：
Product Description:
The ME16WS04 is a high-performance Wi-Fi 6 module supporting dual-band operation (2.4GHz & 5GHz), designed for high-throughput and low-latency wireless connectivity. With built-in large memory and strong processing capability, it can handle complex networking tasks and multi-device connections. Its rich interfaces and stable performance make it an ideal solution for IoT gateways and data-intensive applications.
Key Features:
ARM STAR-MC1 core at 240 MHz for strong processing performance
Multi-protocol support: Wi-Fi 6 (2.4 & 5 GHz), Bluetooth® 5.4, and IEEE 802.15.4
High sensitivity: Wi-Fi -100 dBm, BLE -98 dBm for stable connectivity
Integrated 4 MB SiP Flash + 512 KB RAM, no external memory required
Optional PCB antenna or U.FL connector
19 GPIOs supporting UART, I2C, SPI, PWM, ADC, SDIO, I2S
Supports QSPI, SWD debugging, and multiple UARTs for easier development
Applications:
Smart home gateways, Industrial data terminals, Video surveillance, Smart displays, IoT edge computing devices
